One-half-inch glazing is set in a gasket and secured at the head with wood blocking and three number ten sheet metal screws. Stud bracing is installed as required behind the finished partition, which features typical corner beads at the gypsum wallboard edges. The glass assembly maintains a fire assembly rating where required and aligns with the finished partition beyond per the reflected ceiling plan.
CORNER BEAD, TYP WOOD BLOCKING AS REQUIRED EQ EQ 1/2" GLAZING MAINTAIN FIRE ASSEMBLY RATING WHERE REQ'D GLAZING SET IN GASKET ALIGN 1/2" (3) #10 SMS SEE RCP FINISHED PARTITION BEYOND STUD BRACING AS REQ'D
