Valve actuator control schematic showing hand switches for open and close, along with valve open, valve closed, and limit switch open and close status indicators. The actuator is wired to panel PC 4101A and located in PLC-71 drop 5 panel PNL-74763.
HS OC VALVE ACTUATOR ZSO ZLO ZSC . ZLC HS . LSR PC 4101A I/I LOCATED IN PLC-71 DROP 5 PANEL (PNL-74763)
