This diagram details the modulating damper actuator input and output control points for hearth ten. It features terminal designations for damper position, limit switches, and open-closed status indications. The wiring and control loops connect directly to the building automation and mechanical systems.
ZT . ZI . DAMPER ACTUATOR ZSC . ZSO . . ZLC . ZLO HS . LR HS . OSC SEE TYPICAL MODULATING DAMPER ACTUATOR I/O FOR HEARTH 10
