Finish tile is mounted on the exterior of a circular column. The tile is supported by a substrate and cold-formed steel stud or hat channel framing, sized and detailed per architectural drawings and interior elevations.
TILE MOUNTED ON COLUMN, SEE ELEVATIONS FOR FINISH TILE SUBSTRATE AND STUD/HAT CHANNEL, SEE ARCH DWGS.
