An on-surface dripline flush point installation is situated at finish grade. A subterranean emitter box houses the flush cap and easy fit compression fittings attached to half-inch polyethylene blank tubing. The tubing connects via barb-by-male fittings to a PVC schedule 40 tee or elbow at the exhaust header. The assembly rests on a three-inch minimum depth of three-quarter-inch washed gravel adjacent to brick pavers. A note requires a minimum of six inches of dripline tubing inside the valve box to direct flushed water outside the box.
MULCH FLUSH CAP FOR EASY FIT COMPRESSION FITTINGS: POTABLE:RAIN BIRD MDCFCAP EASY FIT COUPLING: RAIN BIRD MDCFCOUP SUBTERRANEAN EMITTER BOX: RAIN BIRD SEB 7XB 12 " POLYETHYLENE TUBING: RAIN BIRD XF BLANK TUBING FINISH GRADE PVC EXHAUST HEADER PVC SCH 40 TEE OR EL BARB X MALE FITTING: RAIN BIRD XFF-MA FITTING (TYPICAL) ON-SURFACE DRIPLINE: RAIN BIRD XF SERIES DRIPLINE POTABLE: XFCV DRIPLINE 3-INCH MINIMUM DEPTH OF 3/4 " WASHED GRAVEL BRICK (1 OF 2) NOTE: 1. ALLOW A MINIMUM OF 6-INCHES OF DRIPLINE TUBING IN VALVE BOX IN ORDER TO DIRECT FLUSHED WATER OUTSIDE VALVE BOX. © 2 3 2 3 4 5 1 © 6 (7) (8) ( 9) (1 0. / a 6 © 8 8 11 12
