Mechanical · I-5BXS3

Emergency Sludge Storage Tank Duct Flow Diagram

About this detail

Mechanical duct connection pointing to the emergency sludge storage tank with a capacity of nine thousand cubic feet per minute. A secondary directional flow indicator links to the same emergency sludge storage tank.

C . TO EMERGENCY SLUDGE STORAGE TANK I-00-615 F . TO EMERGENCY SLUDGE STORAGE TANK (9000 CFM) I-00-615

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
