Remote Control Valve Assembly in Valve Box

Materials

Brick

Elements

Stairs Connections / Plates

Connections

Rebar Splice / Development

About this detail

A remote control valve assembly is housed within a specification-grade rectangular valve box supported by a minimum five-inch layer of three-quarter-inch crushed gravel over landscape fabric and solid brick supports. The piping network integrates one-inch polyvinyl chloride schedule eighty unions, nipples, elbows, and bushings connecting a mainline to a disc filter, a pressure regulator, a ball valve, and a remote control valve. Control wires feature a twenty-four-inch coil and a waterproof wire splice connection alongside an identification tag. The valve box lid is positioned half an inch above finished grade in turf areas or two inches above soil or mulch in shrub areas.
