Plumbing · I-4VR48

Typical Pop-Up Installation Detail

Elements

About this detail

Lawn and shrub pop-up spray heads connect to a PVC lateral line via a schedule 40 PVC tee, schedule 40 PVC street elbows, and a one-half-inch schedule 80 PVC nipple of required length. The assembly is positioned relative to a curb, walk, headerboard, wall, fence, or building finish grade. Clearances include one-half inch to one-and-one-half inches at lawn edges and four inches to twelve inches at vertical building elements.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
