A target-type flow switch is mounted to a piping system using a thread-o-let or other approved fitting to accommodate adjacent piping. The internal vane or element is trimmed to the manufacturer's recommended length based on pipe dimensions. An extension is provided as required to clear any piping insulation. A single-pole double-throw dry contact switch is enclosed in a NEMA 4X cover, complete with a conduit outlet connection for electrical integration.
CONDUIT HUB (TYP) THREAD-O-LET OR OTHER FITTING AS REQUIRED TO ACCOMMODATE ADJACENT PIPING (TYP). TRIM VANE/ELEMENT AS REQUIRED AND ACCORDING TO MANUFACTURER'S RECOMMENDED LENGTH. PROVIDE EXTENSION AS REQUIRED TO ACCOMMODATE THE PIPING INSULATION WHERE APPLICABLE. SPDT DRY CONTACT SWITCH ENCLOSED IN NEMA 4X COVER. CONDUIT OUTLET CONNECTION FLOW WELDED CONNECTION
