An eight-inch high-density polyethylene pipe connects to the discharge of the wet scrubber drain pump, utilizing a dismantling joint typical of three on the pump discharge. Seal water piping feeds into the system through valve V-71754, regulated by flow switch FSL 1624 and temperature switch TSH 1724. Hand switches HS 1724A and HS 1724B control the standby pump operation.
TSH 1724 FSL 1624 S . . SEAL WATER 2W P-71724 WET SCRUBBER DRAIN PUMP 3 (STANDBY) V-71743 V-71754 HS 1724B LOS LCS HS 1724A START B 8"-SW-HDPE 8"-SW-HDPE DISMANTLING JOINT (TYPICAL OF 3 ON PUMP DISCHARGE)
