The damper actuator control assembly includes status and control points for position sensing and operation. Signal designations include ZT, ZI, ZSC, ZSO, ZLC, ZLO, and HS connections. Reference is made to the typical modulating damper actuator input/output scheme for hearth 5.
ZT . ZI . DAMPER ACTUATOR ZSC . ZSO . . ZLC . ZLO HS . LR HS . OSC SEE TYPICAL MODULATING DAMPER ACTUATOR I/O FOR HEARTH 5
