The control panel assembly consists of multiple I/O modules and drops located at the SCB basement next to the wet scrubber booster skid 2 and the SCB control room at the north end of the control console. The system includes PLC 72 I/O drop 1 for panel PNL-74762 control console-furnace 2 and PLC 72 I/O drop 2 for panel PNL-71751 wet scrubber 2 system control panel. Modules include power supplies, input/output cards, communication modules, and terminal units provided by the wet scrubber system supplier.
I/O I/O I/O I/O CRA PS PS T XBE 31210 I/O I/O I/O I/O I/O I/O I/O I/O CRA PS PS T XBE 31210 NRP 0201 I/O I/O I/O I/O SCB CONTROL ROOM: NORTH END OF CONTROL CONSOLE SCB BASEMENT: NEXT TO WET SCRUBBER BOOSTER SKID 2 PLC 72 I/O DROP 1 PLC 72 I/O DROP 2 PNL-71751 WET SCRUBBER 2 SYSTEM CONTROL PANEL PNL-74762 CONTROL CONSOLE-FURNACE 2 I/O DROP PROVIDED BY WET SCRUBBER SYSTEM SUPPLIER I/O
