Sludge Grinder 2 features five control and status points labeled for ready, fail, running, start command, and stop command operations. The ready status is designated by tag YI 1002, the fail alarm by tag YA 1002, and the running status by tag YIR 1002. The start command uses tag YC 1002 and the stop command uses tag YCS 1002. Each point is represented with instrument bubble symbols and associated wiring or communication links.
YIR 1002 RUNNING YIR 1002 RUNNING YI 1002 READY YI 1002 READY YCR 1002 CMD START YCR 1002 CMD START YCS 1002 CMD STOP YCS 1002 CMD STOP YA 1002 FAIL YA 1002 FAIL SLUDGE GRINDER 2
