A five-eighths inch by eight foot copper grounding rod is driven into the earth and connected via a grounding rod clamp to a number 6 AWG bare copper wire. The wire routes through a one-inch PVC electrical conduit and sweep for earth ground. A ten-inch round valve box with a locking lid sits over the top of the rod, resting on a three-inch minimum depth of three-quarter-inch washed gravel. The assembly is set below finished grade and pavement, maintaining a minimum wire depth of twenty-four inches.
PAVEMENT. FINISHED GRADE. GROUNDING ROD CLAMP. # 6 AWG BARE COPPER WIRE. 1" PVC ELECTRICAL CONDUIT AND SWEEP FOR EARTH GROUND. 8'-0" 24" MIN WIRE DEPTH 4-8" 8'-0" TO 12'-0" 5/8 " X 8' - 0" COPPER GROUNDING ROD. 10" ROUND VALVE BOX WITH LOCKING LID. 3-INCH MINIMUM DEPTH OF 3/4-INCH WASHED GRAVEL 7^ l <i 2 ------ V 2 n ^ <7 <7 a <7 ' \A M. )C )C © 0 h- J L
