A protective pipe bollard is positioned in front of roof drains and overflow drains adjacent to an exterior wall. A roof drain connects through a threaded connection and penetrates the exterior wall, maintaining a minimum slope of 1/8 inch per foot. Sealant is applied as required around penetrations and joints. The floor finish slopes toward the drain assembly.
EXTERIOR WALL FINISH FLOOR SLOPE 1/8"/FT.MIN SEAL AS REQUIRED ROOF DRAIN SEE PLAN FOR SIZES THREADED CONNECTION SEAL AS REQUIRED G010 B5 PIPE BOLLARD IN FRONT OF ROOF DRAINS AND OVERFLOW DRAINS
