The assembly consists of a concrete slab bearing on a four-inch gravel layer over a prepared subgrade. A sixty-mil spray-applied waterproofing membrane is applied beneath the slab, topped with a protection course and a base layer. An underslab vent system is embedded within the gravel layer. The subgrade is compacted prior to placing the gravel and drainage layers.
GM-6.0 C GM-6.4 E.SHIELD 205 PROTECTION COURSE E.SPRAY 60 MILS GM-6.1 A A 4" 1/8"± SLAB 4" GRAVEL LAYER (BY OTHERS) A GM-6.4 T.O.S. SUBGRADE E.VENT H GM-6.4 GM-6.4 F E.BASE 205
