System No. C-AJ-7051 provides a tested firestop assembly achieving a three-hour F rating and one-hour T rating under ANSI/UL 1479 and ASTM E814 standards, alongside CAN/ULC S115 ratings including three-hour F and FH ratings and one-hour FT and FTH ratings. The drawing displays a table of these hourly classifications alongside a plan view and section view marked with component callouts. Numbered markers identify the specific assembly layers, substrate conditions, and joint seal materials. This configuration establishes tested fire protection performance for construction joints.
ANSI/UL1479 (ASTM E814) CAN/ULC S115 F Rating - 3 Hr F Rating — 3 Hr T Rating - 1 Hr FT Rating - 1 Hr FH Rating - 3 Hr FTH Rating - 1 HR R Classi fied by Under writer s Labor atorie s, Inc. to UL 1479 and CAN/ ULC- S115 A System No. C-AJ-7051 C C L A S S I F I E D US 2 3B 4 3A 1
