Architectural · G-X25K7

Accessibility Ramp Slope and Landing Layout

Elements

Stairs Ramps

About this detail

Accessibility ramp profile indicating a maximum slope of 1:12, a maximum run of 30 inches between landings, a maximum rise of 30 inches, and level landing areas at transitions.

SURFACE OF RAMP 30" MAX RUN 30" MAX LEVEL LANDING LEVEL LANDING MAX SLOPE 1:12
