A sixty mil thick fluid-applied waterproofing membrane is applied over a base layer and concrete substrate, featuring a six-inch overlap sealed with a twenty dry-mil tack coat. An overlying protection course shields the waterproof membrane from subsequent construction operations.
20 dry mil E.SPRAY 'TACK COAT' 6" LAP 60 mil THICK E.SPRAY E.SHIELD 205 PROTECTION COURSE A - E.BASE 205
