An electric vehicle charging station is mounted on a post anchored to a concrete slab, providing an operable reach range between 15 inches and 48 inches above the finished surface to accommodate users in wheelchairs. The charging station unit faces the parking stall, with conduits routed through the concrete slab per general contractor coordination. The centerline of the charger aligns with the parking stall striping or grid line as indicated on the plans, and includes a concrete pad where required. Attachment methods follow manufacturer recommendations, and conduit routing coordinates with the concrete slab and structural layout.
