An electrical device and an air intake are mounted on a roof assembly near a parapet wall, door, and openable windows, governed by mandatory minimum separation distances. The electrical device requires a minimum height of three feet, a ten-foot horizontal clearance from the openable window or door, a ten-foot separation from the air intake, and a four-foot minimum clearance from the property line. The air intake maintains a ten-foot separation from openable windows or doors and a three-foot minimum clearance from the parapet wall.
PL PARAPET WALL 10' MIN. 10' MIN. OPENABLE WINDOW OR DOOR AIR INTAKE ELECTRICAL DEVICE 3' MIN. 10' MIN. 3' MIN. 4' MIN. ROOF
