Restroom door signage mounting requirements and geometric specifications position the sign with its centerline aligned to the door centerline at a mounting height between fifty-eight inches and sixty inches above the finished floor to the top of the sign, complying with California Building Code section 11B-703.7.2.6. The sign plate has a thickness of one-quarter inch with eased edges of one-sixteenth inch minimum or chamfered at one-eighth inch maximum. The International Symbol of Accessibility is superimposed and used only at compliant restrooms, with symbol and letter colors contrasting against the background.
12" EASE / ROUND EDGES 1/16" MIN OR CHAMFER AT 1/8" MAX (TYP) (11B-703.7.2.6.4) 11B-703.7.2.6 58" MIN - 60" MAX AFF S16 CENTERLINE OF DOOR 1. 2. 3. 4. 5. NOTES: PROVIDE SIGN AT ALL WOMEN /GIRLS RESTROOM DOORS U.N.O. MATERIAL TO BE 1/4" THICK w/ EASED EDGES COLOR OF SYMBOLS AND LETTERS TO CONTRAST w/ BACKGROUND ISA SYMBOL SHALL ONLY BE USED AT 2025 CBC COMPLIANT RESTROOMS SYMBOLS TO BE SUPERIMPOSED PER 2025 CBC (TYP)
