This wall section details a concrete dumpster enclosure wall supported by a concrete footing. A four-inch long attachment angle connects to a steel embed plate located at the base of the wall, with sizes and dimensions coordinated per structural drawings. The assembly interfaces with surrounding soil and a concrete slab.
4" LONG ATTACHMENT ANGLE, SEE STRUCTURAL STEEL EMBED PLATE, SEE STRUCTURAL SEE STRUCTURAL 2'-6" SEE STRUCTURAL
