Protruding objects maintain a minimum clear width when located greater than twenty-seven inches above the finished floor or finished ground, with a maximum four-inch projection allowed for objects at or below twenty-seven inches. Handrails are permitted to extend four and one-half inches into the circulation path per 2022 CBC Section 11B-307.2. Protruding elements must not reduce the required clear width of an accessible route or maneuvering space.
WHEN BOTTOM OF OBJECT IS GREATER THAN 27" ABOVE FIN. FLR OR FIN. GROUND CLEAR 6' - 8" MIN. GREATER THAN 2'-3" 2' - 3" OR LESS 4" MAX. ANY AMOUNT REQUIRED CLEAR WIDTH NOTE: PROTRUDING OBJECTS MAY NOT REDUCE THE REQUIRED CLEAR WIDTH OF AN ACCESSIBLE ROUTE OR MANEUVERING SPACE. * HANDRAILS ARE PERMITTED TO EXTEND 4-1/2" INTO CIRCULATION PATH PER 2022 CBC 11B-307.2 WHEN BOTTOM OF OBJECT IS 27" OR LESS ABOVE FIN. FLR OR FIN. GROUND
