Ramp handrail and warning curb assemblies and dimensional requirements feature a top handrail positioned between thirty-four and thirty-eight inches above the ramp surface. A vertical rail is located beyond the handrail with a horizontal railing above an optional two-inch minimum curb. A forty-two inch minimum guardrail is required if the ramp is higher than thirty inches. A four-inch minimum high warning curb is required at ramps when a drop-off of more than six inches exists between the ramp surface and the adjacent grade, with a six-inch warning curb utilized where applicable. Adjacent walls or surfaces must remain free of sharp or abrasive elements, and pipe dimensions are specified as nominal diameter.
42" MIN WHERE GUARDRAIL REQ 34" - 38" 30" MAX LEVEL AREA OPTIONAL CURB, 2" H MIN RAMP VERTICAL RAIL BEYOND TOP HANDRAIL NOTE: IF RAMP IS HIGHER THAN 30" A 42" HIGH GUARDRAIL IS REQUIRED 4" MIN HIGH WARNING CURB AT RAMPS, IF A DROP-OFF OF MORE THAN 6" EXISTS BETWEEN THE RAMP SURFACE AND THE ADJACENT GRADE, A 6" WARNING CURB MUST BE UTILIZED HORIZONTAL RAILING 2" MIN TO 4" MAX MIN 1 1/2" NOTE: WALL OR OTHER SURFACE ADJACENT TO HANDRAIL(S) MUST BE FREE OF SHARP OR ABBRASIVE ELEMENTS NOTE: PIPE DIMENSIONS ARE SHOWN AS NOMINAL DIAMETER 18" MIN
