A galvanized steel fence post sits inside a matching galvanized pipe sleeve embedded within a precast concrete barrier. The annular space between the post and the sleeve is filled with an epoxy grout resin compound. The precast concrete barrier is fabricated with post holes to provide structural support for the embedded fence posts.
60.5 Ø GALVANIZED PIPE (LINE POST) 76.3 Ø GALVANIZED PIPE (CORNER POST) DRILLED OR PREFABRICATED HOLE FOR 75 Ø GALVANIZED PIPE SLEEVE (LINE POST) OR 100 Ø GALVANIZED PIPE SLEEVE (CORNER POST) FILLED WITH EPOXY GROUT RESIN COMPOUND PRECAST CONCRETE BARRIER WILL BE CAPABLE OF BEING DRILLED OR FABRICATED WITH POST HOLES TO SUPPORT EMBEDDED FENCE POSTS SECTION 'A'
