An adjustable metal fitting is constructed from a 42.7 millimeter diameter tubular section with a 2.3 millimeter wall thickness and a flat bar component designated as FB-38x3. The assembly includes a 13 millimeter diameter pin hole on the flat bar and two 12 millimeter diameter holes along the tubular section. Overall dimensions span a length of 125 millimeters with detailed spacing of 20, 50, 40, and 15 millimeters.
ADJUSTABLE METAL FITTING 20 30 20 70 20 50 40 15 125 Ø42.7 2.3 Ø42.7x2.3 Ø12 FB-38x3 Ø13
