Tactile signage for restroom doors is specified with a 1/4-inch thick material featuring eased edges rounded to a minimum of 1/16-inch or chamfered to a maximum of 1/8-inch. The triangular sign geometry requires vertices radiused between 1/8-inch and 1/4-inch with a side length of 12 inches. Installation is positioned with the centerline aligned with the door vertex and height set between 58 inches minimum and 60 inches maximum above the finished floor. Symbols and letters must maintain contrasting colors with the background and comply with CBC requirements.
12" 11B-703.7.2.6 58" MIN - 60" MAX AFF CENTERLINE OF DOOR VERTICES SHALL BE RADIUSED 1/8"-1/4" TYP (11B-703.7.2.6.4) S17 EASE / ROUND EDGES 1/16" MIN OR CHAMFER AT 1/8" MAX (TYP) (11B-703.7.2.6.4) 1. 2. 3. 4. 5. NOTES: PROVIDE SIGN AT ALL MEN / BOYS RESTROOM DOORS U.N.O. MATERIAL TO BE 1/4" THICK w/ EASED EDGES COLOR OF SYMBOLS AND LETTERS TO CONTRAST w/ BACKGROUND ISA SYMBOL SHALL ONLY BE USED AT 2025 CBC COMPLIANT RESTROOMS SYMBOLS TO BE SUPERIMPOSED PER 2025 CBC (TYP)
