An internally illuminated exit sign layout requires a minimum letter height of 6 inches with a 3/4 inch stroke width and a 3/8 inch minimum letter spacing except for the letter 'I', which maintains a 2 inch minimum separation. The sign must be connected to the emergency power system and remain continuously illuminated.
3/8" MIN. SPACING 6" MIN. 3/4" MIN. 3/4" MIN. 2" MIN EXCEPT FOR THE LETTER "I" NOTES: 1. PROVIDE INTERNALLY LIT SIGN POWERED BY EMERGENCY POWER SYSTEM. 2. SIGN TO REMAIN ILLUMINATED AT ALL TIMES. 3'=1'-0" 6" = 1'-0" G004 8 REQUIRED SIGN /
