The end of the conduit is packed with closed-cell polyurethane foam surrounding the internal cables or conduits. A minimum depth of six inches of foam is applied to seal the conduit end.
6" MIN. END OF CONDUIT CLOSED CELL POLYURETHANE FOAM A GM-5.1
