The steel stud bottom track is anchored directly to the top of the structural concrete slab using 0.145-inch shot pins spaced at twenty-four inches on center with a maximum six-inch distance from ends per ICC schedule. Batt insulation fills the stud cavity between wall finishes attached with number 6 type S self-drilling screws. A continuous firestop sealant is applied at the floor line adjacent to the floor finish.
BOTTOM TRACK TO BE ANCHORED TO SLAB W/ 0.145 SHOT PINS. EMBED 1" MIN @24" O.C., 6" MAX FROM ENDS PER ICC SCHEDULE PER SCHEDULE, APPLIED VERT. AND ATTACHED WITH #6 TYPE S 1 1/8" SH SCREWS, MIN 1" EMBEDDMENT @ 18" AROUND PERIMETER AND 12" OC @ INTERMEDIATE STUDS AND PER ICC #ESR-3064P TOP OF STRUCTURAL SLAB CONTINUOUS FIRESTOP SEALANT BATT INSULATION WALL FINISH RE: FINISH PLANS FLOOR FINISH PER SCHEDULE A-B02 - BOTTOM OF PARTITION @ SLAB
