G-AVVK4 — Single-Ply Membrane Roofing on Concrete Slab and Metal Deck

Architectural · G-AVVK4

Single-Ply Membrane Roofing on Concrete Slab and Metal Deck

Materials

Concrete Metal (misc.)

Elements

Roofs Floors / Slabs Decks Waterproofing / Flashing Insulation

About this detail

The roof assembly consists of a single-ply membrane roofing adhered over R-30 roof insulation and a vapor retarder. Below the insulation lies a concrete slab poured over a metal deck, with concrete reinforcement sized per structural drawings.

SINGLE PLY MEMBRANE ROOFING METAL DECK R-30 ROOF INSULATION CONCRETE SLAB RE: STRUCTURAL VAPOR RETARDER
