Exit Sign Mounting and Clearances at Door Opening

Elements

About this detail

An exit sign is mounted centrally above the exit access door, positioned six inches below the finished ceiling per the reflected ceiling plan. A self-luminous door-mounted exit sign and a wall-mounted exit sign comply with CBC 11b-1013.7. Raised letter signage is installed adjacent to the door frame per detail at seven feet above the finished floor, with an additional self-luminous sign placed eight inches above the floor. The door frame is provided per interior design standards.
