Restroom Fixture Mounting Heights and ADA Clearances

Elements

About this detail

Mounting heights and vertical dimensions are established for standard, ADA compliant, and children's restroom fixtures relative to the floor line. Lavatory rim heights range from two feet zero inches for standard, one foot five inches for ADA, and one foot six inches for children. Toilet seat heights measure one foot two inches to one foot three inches standard, one foot five inches to one foot seven inches ADA, and one foot one inch for children. Urinal lip heights are set at two feet zero inches standard and one foot five inches ADA, with children's heights at one foot six inches. Lavatory rim top heights are dimensioned at three feet zero inches standard, two feet nine inches to three feet zero inches ADA, and two feet zero inches for children.
