General · G-79H47

Toilet Grab Bars

Units: imperial
Sheet: G6
Discipline: General

Elements

Walls

Text on the drawing

REAR WALL GRAB BARS NOTE: HANDLE SHALL BE ON OPEN SIDE 17" - 19" 33"- 36" 17" - 19" SIDE WALL GRAB BARS 12" MAX 42" MIN 39" - 41" 18" MIN 39" - 41" 1 1/2" MIN 24" MIN 12" MIN 36" MIN 54" MIN

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
