A pole-mounted parking stall sign stands adjacent to a pedestrian walk with a minimum clearance of six feet eight inches when located in an accessible route, and five feet minimum above the finish grade. A curb separates the walk from the parking space, where a wheel stop is positioned at a minimum distance of two feet from the curb. The walk width is dimensioned at four feet minimum, with an adjacent two-foot curb dimension.
6'-8" MIN WHEN LOCATED IN AN ACCESSIBLE ROUTE 5'-0" MIN ABOVE FINISH GRADE PARKING STALL SIGN (POLE MTD) SEE DETAIL 1 & 2 WHEEL STOP CURB WALK 2'-0" MIN 2'-0" 4'-0"
