Exposed pipes under the lavatory require insulation while maintaining smooth surfaces free of sharp or abrasive edges below the basin. A wall-mounted mirror is positioned above the sink. The assembly provides required knee and toe clearances beneath the lavatory for accessibility compliance.
INSULATE PIPE WHEN EXPOSED (NO SHARP OR ABRASIVE SURFACES BELOW LAVATORY) MIRROR UNDER LAVATORY CLEARANCES
