An internally lit exit sign is powered by an emergency power system and remains illuminated at all times. The sign features letters with a minimum height of six inches and specific minimum spacing requirements, including three-eighths inch letter spacing, three-quarters inch border clearances, and a two-inch minimum except for the letter I.
3/8" MIN. SPACING 6" MIN. 3/4" MIN. 3/4" MIN. 2" MIN EXCEPT FOR THE LETTER "I" NOTES: 1. PROVIDE INTERNALLY LIT SIGN POWERED BY EMERGENCY POWER SYSTEM. 2. SIGN TO REMAIN ILLUMINATED AT ALL TIMES.
