Existing piping layouts feature a 1.5-inch 3WLP line, a 2-inch vacuum clean line, a 3-inch 3W line, a 3-inch polymer solution pipe, and a 6-inch drain line equipped with an expansion joint. The system routes through existing structural supports and utilizes labeled tag callouts for system identification.
EXISTING 1 112" 3WLP(B1 EXISTING 2" VACUUM CLEAN EXISTING 3" 3W(B1 B1 \ r fit I 4 * i . 4 - « j It f 0 r ri± EXISTING 3" POLYMER SOLUTION (TYP 2) EXISTING 6" DRAIN B2 A2 EXISTING JOINT
