An existing open web steel joist support connection is strengthened with a new 3/8-inch plate added under the horizontal leg of the continuous support angle and the joist top chord flange. Fillet welds of 5/16-inch secure the plate to the continuous angle and the joist top chord typically. An existing diagonal wide flange beam and metal deck above frame into the structural system, with additional support provided via a skewed beam-to-beam connection utilizing a bolted shear tab.
B SECTION B-B 1"=1'-0" C SECTION C-C 1"=1'-0" W8x24 BM PER PLAN SKEWED BM TO BM CONN PER TYP DETAIL W/ BOLTED SHEAR TAB SEE F8/01.SF.502 FOR STL PL TO CONC WALL CONN (E) CONC WALL 7 1/4" 4 3/4" TYP 1 1/2" TYP 3" (E) DIAGONAL WF BM PER PLAN (E) CONT DECK SUPPORT ANGLE (E) OWSJ 5/16 3/8" PL TO CONT ANGLE, TYP 5/16 3/8" PL TO OWSJ TOP CHORD, TYP (N) 3/8" PL UNDER HORIZONTAL LEG OF ANGLE & OWSJ TOP CHORD FLANGE (E) MTL DECK ABOVE AS NOTED C2 PARTIAL PLAN AT (N) BEAM SUPPORT
