F-MKGZ6 — Fire Protection System Plan Detail with Structural Members

Fire Protection · F-MKGZ6

Fire Protection System Plan Detail with Structural Members

About this detail

This plan detail shows structural steel members and a fire protection zone layout with dimensions of 1 foot 2 3/8 inches, 5 feet 2 3/8 inches, 1 foot 2 3/4 inches, and 2 feet 9 1/2 inches. Reference tags 2N4, 564, 0G4, and 292 indicate specific components and locations within the framing grid.

292 2N4 564 0G4 1' - 2 3/8" 5' - 2 3/8" 1' - 2 3/4" 2' - 9 1/2"

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
