A W6X20 beam connection utilizes a 3/8 inch by 4 1/2 inch by 0 feet-6 1/2 inch A36 steel shear plate fastened with two three-quarter-inch A325N bolts at the end of the beam. A separate connection detail features a W27 or smaller supporting member utilizing flange plates measuring 13/16 inch by 12 1/4 inch and a half-inch web plate, with three-sixteenths-inch fillet welds indicated at intersecting steel elements. Shear plate and bolt sizes are otherwise referenced to the structural schedule for typical conditions. Spacing dimensions are provided for bolt holes, edge distances, and plate clearances.
316 / 316 / W6X20 SHEAR TAB CONNECTION SCALE: 1 1 2 / " = 1'-0" D5 W27 OR SMALLER 1 12 / " WELD "A" SEE SCHED 3" 3" 3" B SEE SCHEDULE FOR SHEAR PLATE AND BOLTS TYP 4 1 2 / " 1 3 4 / " b 1" 2" 2 1 2 / " f 3" 2" 2 14 / " 2 14 / " 6 1 2 / " 12 / 12 / 1" 7" 5" AT END BEAM (2) 3 4 / " A325N BOLTS FL 3 8 / "X4 1 2 / " X 0'-6 1 2 / " A36 SHEAR PLATE 12 / " WEB_PLATE PL 13 16 / "X12 1 4 / " FLANGE_PLATE PL 13 16 / "X12 1 4 / " FLANGE_PLATE W6X20 W6X20 1 1 2 / "
