F-JJ8FQ — Firestop Penetration System for Floor Assembly

Fire Protection · F-JJ8FQ

Firestop Penetration System for Floor Assembly

About this detail

Through-penetrating items pass through a concrete floor slab with a two-hour fire rating and zero to two-hour T ratings. The plan and cross-section views feature multiple penetrants and sleeve configurations organized in accordance with System No. C-AJ-8177. Section A-A details the interface between the penetrating items, sleeve components, and the surrounding concrete floor structure.

System No. C-AJ-8177 SECTION A-A F Rating - 2 Hr T Ratings - 0, 1/4, 1-1/2 and 2 Hr (See Items 2, 3, 4, 5 and 6) A A 4 2 3 5 6 1 7 4 2 7B 7A 3

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
