A vertical pipe penetrates a concrete floor slab or composite metal deck floor assembly through a six-inch galvanized pipe sleeve. The annular space contains fiberglass insulation and a backer rod, sealed at both sides with firestopping material at rated floors or acoustical sealant in a one-quarter-inch perimeter gap. A galvanized floor plate is secured at the top of the sleeve and sealed with waterproof caulk on waterproof floors only. Pipe insulation is applied where required along the vertical run.
CONCRETE FLOOR SLAB WATERPROOF CAULK (WATERPROOF FLOORS ONLY) PIPE INSULATION (WHERE REQD) PIPE FIRESTOPPING MATERIAL AT RATED FLOORS (TYP BOTH SIDES) GALVANIZED PIPE SLEEVE METAL DECK 6" BACKER ROD FIBERGLASS INSULATION 1/4" GAP AROUND PERIMETER FILLED WITH ACOUSTICAL SEALANT (TYP BOTH SIDES) GALVANIZED FLOOR PLATE WELD
