A one-inch schedule forty sprinkler main connects via a tee and elbow to a horizontal return pipe of variable length to suit field conditions. A vertical drop pipe connects through a one-by-one-half-inch pipe reducing coupling to a chrome pendent sprinkler head. A chrome escutcheon plate finishes the penetration at the tile ceiling where the sprinkler head is centered.
TEE AND ELBOW PROVIDE LENGTH TO SUIT PROVIDE LENGTH TO SUIT 1" X 1/2" PIPE REDUCING COUPLING CHROME PENDENT SPRINKLER HEAD CENTERED IN TILE CEILINGS CHROME ESCUTCHEON PLATE 1" SCH 40 SPRINKLER MAIN
