An HSS 6x3x1/4 louver support post is connected via two 3/8-inch by 4-inch by 0-foot 6-inch shear plates to a 1/2-inch by 10-1/2-inch by 1-foot 4-inch embed plate. The embed plate is secured to a 12-inch concrete masonry unit wall using eight 3/4-inch diameter by 0-foot 6-inch welded studs. This embed detail is identical at both the top and bottom of the post.
4" 4" 4" 116 / 116 / 6 14 / " 6 14 / " 8" 8" 2" 2" 1'-4" 10 1 2 / " 11 5 8 / " EMBED DETAIL IS THE SAME AT TOP AND BOTTOM OF POST 12" CMU WALL FL 3 8 / "X4" X 0'-6" SHEAR_PLATE FL 3 8 / "X4" X 0'-6" SHEAR_PLATE HSS6X3X 1 4 / (8) 3 4 / " Ø X 0'-6" WELDED STUD FL 1 2 / "X10 1 2 / " X 1'-4" EMBED_PLATE B3 08.SF.201
