F-B4YDK — Ventilator Wall Mounting Bracket Detail

Mechanical · F-B4YDK

Ventilator Wall Mounting Bracket Detail

Elements

About this detail

A mounting bracket provided by the manufacturer attaches directly to the wall using fasteners installed by the ventilator installer. The top of the ventilator aligns with hanging mounting rods positioned at a distance of 1.375 inches from the bracket face, with a vertical spacing dimension of 2 inches.

2 [51] 1.375 [35] DETAIL 2 TOP OF VENTILATOR FASTEN TO WALL BY VENTILATOR INSTALLER MTG. BRACKET BY GAYLORD MOUNTING RODS BY VENTILATOR INSTALLER FASTEN TO WALL BY VENTILATOR INSTALLER DETAIL 1
