A mounting bracket provided by the manufacturer is secured to the wall using fasteners installed by the ventilator contractor. Mounting rods and top of ventilator connections are coordinated in the field. Dimensions of 1.375 inches and 2 inches locate the bracket attachment relative to the wall face.
2 [51] 1.375 [35] DETAIL 2 TOP OF VENTILATOR FASTEN TO WALL BY VENTILATOR INSTALLER MTG. BRACKET BY GAYLORD MOUNTING RODS BY VENTILATOR INSTALLER FASTEN TO WALL BY VENTILATOR INSTALLER DETAIL 1
