An in-duct smoke detector is mounted within a ductwork run that penetrates a one-hour rated wall equipped with a ceiling damper. A four-square deep junction box connects via three-quarter-inch raceways, while a half-inch raceway extends to a remote LED indicator when required. A pancake box links the detector to the electrical wiring. A minimum twenty-four by twenty-four-inch access door or hatch, furnished by others, is located directly below the detector in the ceiling. A minimum twelve-inch access door is also provided on the ductwork.
DIRECTLY BELOW DETECTOR MOUNTING IN SUPPLY OR RETURN DETECTOR (MINIMUM 12") ACCESS DOOR MIN. SIZE 24"x24" ACCESS DOOR/HATCH (F.B.O.) CEILING DAMPER PANCAKE BOX (WHEN REQUIRED) DUCT WORK REMOTE LED 1/2" RACEWAY IN-DUCT SMOKE DETECTOR MOUNTING DETAIL typical connection DETECTOR 3/4" RACEWAY 3/4" RACEWAY 4S DEEP JBOX (1HR) RATED WALL (F.B.O.)
