Electrical wiring connections for a fire sprinkler bell controlled through an FCM-1 addressable module. The signaling line circuit loop connects to terminals T1 and T2 for incoming signals and loops to the next device. A 24VDC non-resettable power supply connects to terminals T10 and T11 for external power. An end-of-line 4.7K resistor is wired across the positive and negative terminals at the sprinkler bell assembly.
(+) (-) (-) (+) EOL 4.7K SPRINKLER BELL SLC LOOP TO NEXT DEVICE SLC LOOP FROM "FACP" OR PREVIOUS DEVICE 24VDC NON-RESETTABLE POWER FROM "FACP" OR PREVIOUS DEVICE (+) (-) SPRINKLER BELL WIRING DETAIL typical connection FCM-1 ONES TENS LOOP ADDRESS TOP SLC (-) T1 SLC (+) T2 T7 SUP T6 SUP AB(-) AB(+) T9 A(-) T8 A(+) T11 Ext PWR (-) T10 Ext PWR (+)
